MADOCA: Final Products(JXF) Quality Monitor

GPS Week 2269, 2023/07/02-2023/07/08

MADOCA: Final Products(JXF) Quality Monitor

Graph:

GPS , GLONASS , QZSS , Galileo , BeiDou , GPS Satellite Clock , FCB

JXF Monitor Statistics

prev top next

Date DOY Product GPS Errors wrt IGR QZS Errors wrt COM GLONASS Errors wrt IGV GLONASS Errors wrt IAC Galileo Errors wrt GBM BeiDou(GEO) Errors wrt GBM BeiDou(IGSO) Errors wrt GBM BeiDou(MEO) Errors wrt GBM Result Files

Orbit(m) Clock(ns) Orbit(m) Clock(ns) Orbit(m) Orbit(m) Clock(ns) Orbit(m) Clock(ns) Orbit(m) Clock(ns) Orbit(m) Clock(ns) Orbit(m) Clock(ns)

R A C 3D R A C 3D R A C 3D R A C 3D R A C 3D R A C 3D R A C 3D R A C 3D

RMS RMS RMS RMS STD RMS RMS RMS RMS RMS STD RMS RMS RMS RMS RMS RMS RMS RMS RMS STD RMS RMS RMS RMS RMS STD RMS RMS RMS RMS RMS STD RMS RMS RMS RMS RMS STD RMS RMS RMS RMS RMS STD RMS

- - Total 0.0153 0.0147 0.0126 0.0247 0.1560 0.3140 0.1389 0.0827 0.0530 0.1701 0.4280 2.0020 0.0157 0.0373 0.0329 0.0521 0.0272 0.0442 0.0422 0.0669 0.2050 0.8250 0.0140 0.0195 0.0190 0.0306 0.1180 0.1290 - - - - - - - - - - - - - - - - - - jxf2269.tar.gz

2023/07/08 189 jxf22696 0.0144 0.0125 0.0107 0.0218 0.0470 0.2720 0.1680 0.0965 0.0483 0.1996 0.4640 1.8810 0.0130 0.0400 0.0380 0.0567 0.0289 0.0485 0.0464 0.0731 0.1260 0.7500 0.0120 0.0142 0.0138 0.0232 0.0370 0.1070 - - - - - - - - - - - - - - - - - - jxf22696.tar.gz

2023/07/07 188 jxf22695 0.0143 0.0150 0.0121 0.0240 0.0450 0.2480 0.1597 0.0885 0.0525 0.1899 0.4490 1.8450 0.0146 0.0448 0.0349 0.0586 0.0284 0.0487 0.0491 0.0748 0.1320 0.8530 0.0155 0.0215 0.0186 0.0324 0.0480 0.1240 - - - - - - - - - - - - - - - - - - jxf22695.tar.gz

2023/07/06 187 jxf22694 0.0161 0.0182 0.0122 0.0272 0.0510 0.2900 0.1396 0.0894 0.0532 0.1741 0.4030 2.2460 0.0146 0.0412 0.0295 0.0528 0.0257 0.0462 0.0390 0.0657 0.1080 0.8730 0.0136 0.0218 0.0179 0.0314 0.0390 0.1230 - - - - - - - - - - - - - - - - - - jxf22694.tar.gz

2023/07/05 186 jxf22693 0.0154 0.0163 0.0128 0.0258 0.0460 0.2710 0.1285 0.0528 0.0557 0.1497 0.3400 2.2430 0.0159 0.0336 0.0289 0.0471 0.0296 0.0413 0.0365 0.0625 0.1120 0.8240 0.0137 0.0237 0.0201 0.0340 0.0410 0.1030 - - - - - - - - - - - - - - - - - - jxf22693.tar.gz

2023/07/04 185 jxf22692 0.0160 0.0146 0.0125 0.0250 0.0480 0.2750 0.1252 0.0643 0.0578 0.1522 0.3230 2.0810 0.0181 0.0361 0.0302 0.0504 0.0311 0.0427 0.0429 0.0681 0.1370 0.8550 0.0152 0.0195 0.0260 0.0359 0.0500 0.1600 - - - - - - - - - - - - - - - - - - jxf22692.tar.gz

2023/07/03 184 jxf22691 0.0162 0.0132 0.0140 0.0251 0.0530 0.3830 0.1208 0.0691 0.0561 0.1500 0.3300 1.8380 0.0172 0.0324 0.0341 0.0501 0.0245 0.0404 0.0406 0.0623 0.1000 0.8580 0.0147 0.0176 0.0177 0.0290 0.0440 0.1540 - - - - - - - - - - - - - - - - - - jxf22691.tar.gz

2023/07/02 183 jxf22690 0.0142 0.0127 0.0134 0.0233 0.0460 0.4140 0.1228 0.1053 0.0467 0.1684 0.3240 1.8290 0.0162 0.0321 0.0338 0.0494 0.0217 0.0412 0.0404 0.0616 0.0960 0.7600 0.0131 0.0170 0.0170 0.0274 0.0400 0.1220 - - - - - - - - - - - - - - - - - - jxf22690.tar.gz

GPS Orbit/Clock Errors wrt IGR(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

QZSS Orbit/Clock Errors wrt COM(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

GLONASS Orbit Errors wrt IGV(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

GLONASS Orbit/Clock Errors wrt IAC(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

Galileo Orbit/Clock Errors wrt GBM(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

BeiDou(GEO) Orbit/Clock Errors wrt GBM(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next
-     (Plot updates after 5days.)

BeiDou(IGSO) Orbit/Clock Errors wrt GBM(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next
-     (Plot updates after 5days.)

BeiDou(MEO) Orbit/Clock Errors wrt GBM(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next
-     (Plot updates after 5days.)

GPS(G01) Satellite Clock(GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

GPS FCB (GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

QZSS FCB (GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

Galileo FCB (GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next

BeiDou FCB (GPS Week 2269, 2023/07/02-2023/07/08) ↑

prev top next
-     (Plot not updates.)

update: 2023-07-24 22:46:41 UTC

The products are for test and evaluation purpose only.

Date	DOY	Product	GPS Errors wrt IGR						QZS Errors wrt COM						GLONASS Errors wrt IGV				GLONASS Errors wrt IAC						Galileo Errors wrt GBM						BeiDou(GEO) Errors wrt GBM						BeiDou(IGSO) Errors wrt GBM						BeiDou(MEO) Errors wrt GBM						Result Files
			Orbit(m)				Clock(ns)		Orbit(m)				Clock(ns)		Orbit(m)				Orbit(m)				Clock(ns)		Orbit(m)				Clock(ns)		Orbit(m)				Clock(ns)		Orbit(m)				Clock(ns)		Orbit(m)				Clock(ns)
			R	A	C	3D	Clock(ns)		R	A	C	3D	Clock(ns)		R	A	C	3D	R	A	C	3D	Clock(ns)		R	A	C	3D	Clock(ns)		R	A	C	3D	Clock(ns)		R	A	C	3D	Clock(ns)		R	A	C	3D	Clock(ns)
			RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	STD	RMS	RMS	RMS	RMS	RMS	STD	RMS
-	-	Total	0.0153	0.0147	0.0126	0.0247	0.1560	0.3140	0.1389	0.0827	0.0530	0.1701	0.4280	2.0020	0.0157	0.0373	0.0329	0.0521	0.0272	0.0442	0.0422	0.0669	0.2050	0.8250	0.0140	0.0195	0.0190	0.0306	0.1180	0.1290	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf2269.tar.gz
2023/07/08	189	jxf22696	0.0144	0.0125	0.0107	0.0218	0.0470	0.2720	0.1680	0.0965	0.0483	0.1996	0.4640	1.8810	0.0130	0.0400	0.0380	0.0567	0.0289	0.0485	0.0464	0.0731	0.1260	0.7500	0.0120	0.0142	0.0138	0.0232	0.0370	0.1070	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22696.tar.gz
2023/07/07	188	jxf22695	0.0143	0.0150	0.0121	0.0240	0.0450	0.2480	0.1597	0.0885	0.0525	0.1899	0.4490	1.8450	0.0146	0.0448	0.0349	0.0586	0.0284	0.0487	0.0491	0.0748	0.1320	0.8530	0.0155	0.0215	0.0186	0.0324	0.0480	0.1240	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22695.tar.gz
2023/07/06	187	jxf22694	0.0161	0.0182	0.0122	0.0272	0.0510	0.2900	0.1396	0.0894	0.0532	0.1741	0.4030	2.2460	0.0146	0.0412	0.0295	0.0528	0.0257	0.0462	0.0390	0.0657	0.1080	0.8730	0.0136	0.0218	0.0179	0.0314	0.0390	0.1230	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22694.tar.gz
2023/07/05	186	jxf22693	0.0154	0.0163	0.0128	0.0258	0.0460	0.2710	0.1285	0.0528	0.0557	0.1497	0.3400	2.2430	0.0159	0.0336	0.0289	0.0471	0.0296	0.0413	0.0365	0.0625	0.1120	0.8240	0.0137	0.0237	0.0201	0.0340	0.0410	0.1030	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22693.tar.gz
2023/07/04	185	jxf22692	0.0160	0.0146	0.0125	0.0250	0.0480	0.2750	0.1252	0.0643	0.0578	0.1522	0.3230	2.0810	0.0181	0.0361	0.0302	0.0504	0.0311	0.0427	0.0429	0.0681	0.1370	0.8550	0.0152	0.0195	0.0260	0.0359	0.0500	0.1600	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22692.tar.gz
2023/07/03	184	jxf22691	0.0162	0.0132	0.0140	0.0251	0.0530	0.3830	0.1208	0.0691	0.0561	0.1500	0.3300	1.8380	0.0172	0.0324	0.0341	0.0501	0.0245	0.0404	0.0406	0.0623	0.1000	0.8580	0.0147	0.0176	0.0177	0.0290	0.0440	0.1540	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22691.tar.gz
2023/07/02	183	jxf22690	0.0142	0.0127	0.0134	0.0233	0.0460	0.4140	0.1228	0.1053	0.0467	0.1684	0.3240	1.8290	0.0162	0.0321	0.0338	0.0494	0.0217	0.0412	0.0404	0.0616	0.0960	0.7600	0.0131	0.0170	0.0170	0.0274	0.0400	0.1220	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	jxf22690.tar.gz
